Model: Single Post Non-avoiding Parking Lift          Back to Products

Single Post Non-avoiding Parking Lift-D1P2D



Descriptions

Double Arm Non-avoiding Parking Lift

The new model constitutes a rectangular state. When accessing the car, the column is tilted outward, and the small arm (upward) and the lingering arm (tension) sharing the inclined agent, so that the tablet and columns ensure vertical.
During the operation of the underwriting, the underwriting is only under pressure, and there are no adverse conditions such as loosening.
There is a dynamic anti -pendant system; during the work process, if the aging of the chain is broken or the itinerary switch fails, the dynamic anti -fall system will instantly work to protect the vehicle from crash.

Characteristics

High Lifting Capacity: This 3.5t single post auto storage lift is designed to handle heavy vehicles, ensuring safe and efficient parking and maintenance for your car. With a high lifting capacity, you can park two cars at once, perfect for users with multiple vehicles.

Space-Saving Design: The single post design of this lift takes up minimal space, making it ideal for small garages or home workshops. This is a great solution for users with limited space, such as homeowners or small business owners.

Reliable and Durable: With a 12-month warranty, you can trust the quality and durability of this lift. The one cylinder hydraulic lift ensures smooth and stable operation, providing peace of mind for users who value reliability.

Easy Installation: Our product is designed for easy installation, allowing users to quickly set it up and start using it. This is a great feature for users who are not experienced in DIY projects or have limited technical expertise.




Technical Parameter

Item Parameters

Name

Single Post Parking Lifts

Model

D1P2D

 Size of car (L*W*H)

500mm*1900mm*1550mm

 Weight of car

 2000kg

 Size of the lift

5500mm*2500mm*3500mm

 Lift speed

 5m/min

 Fall speed

5m/min

 Slide speed

6.5m/min

Turn speed

 1m/min

Power of supply

 3 phases, 380V, 50HZ, 30A

Lift motor

2.2kw

Sliding motor

0.4kw

Rotate motor

0.4kw

Standard parts

yes

Safety devices

yes
